The LoRaWAN® Rope-Type Water Leak Sensor detects water and other liquid leaks along the entire length of its cable. When liquid touches any point on the cable, the sensor immediately reports it through LoRaWAN®, allowing for fast response to potential damage. Therefore, it is ideal for applications such as garages, kitchens, basements, and other areas prone to leaks.
In addition, the sensor is built for reliability in harsh environments. Its IP68-rated enclosure protects against water and dust, while it operates in a wide -40°C to 85°C temperature range, making it suitable for both indoor and outdoor use. Moreover, its long-range wireless connectivity covers up to 2 km in urban areas and 5 km in line-of-sight conditions, ensuring consistent monitoring even in large spaces.
The device is powered by 2 × AAA batteries, making installation quick and easy without wiring. Furthermore, it offers up to 1 year of operation before replacement. The combination of battery power and wireless technology reduces setup complexity while providing reliable alerts. Most importantly, the sensor integrates seamlessly with the SenseCore Control Suite, where users can receive real-time notifications, track leak events, and manage alerts efficiently.
Key Features
-
Detects water, oil, and other liquid leaks along the full cable
-
Long-range connectivity: up to 2 km (urban) / 5 km (line of sight)
-
Rugged IP68 waterproof and dustproof housing
-
Wide operating temperature: -40°C to 85°C
-
Battery-powered with up to 1 year life (2 × AAA)
-
Easy installation and low maintenance
-
Seamless integration with SenseCore Control Suite
Typical Applications
-
Garages, kitchens, basements, and other leak-prone areas
-
Industrial or commercial facilities needing leak monitoring
-
Large-scale installations in buildings and utility areas
Technical Specifications
General Parameters
-
Product Model: AGLWNPW01
-
Detection Types: Water, oil, and other liquids
-
Detection Mode: Range detection
Wireless Parameters
-
Protocol: LoRaWAN® 1.0.3, Class A
-
Max Transmit Power: 21 dBm
-
Receiver Sensitivity: -137 dBm / 125 kHz SF=12
-
Frequency Band: EU868 / US915
Physical Parameters
-
Sensor Cable Length: 2.0 m (customizable)
-
Power Supply: 2 × AAA 1.5V batteries
-
Operating Temperature: -40°C to 85°C
-
Protection Class: IP68
-
Dimensions: 131 × 62.7 × 27.5 mm
-
Mounting: Wall mounting
